GALAXIE IV 4.5T - Flat tracks - Surfaced-mounted version View larger

Associated products :

GALAXIE IV 4.5T - Flat tracks - Surfaced-mounted version

412 9301D

Passenger Car Light Duty Vehicle

GALAXIE IV 4.5T - Big scissors lift, flat tracks, surfaced-mounted version

Other 4.5T flat tracks

GALAXIE IV 4.5T - Big scissors lift, flat tracks, recessed-mounted version
Ref. 412 9310D

Other available references

BIG SCISSORS 4.5T - WHELL ALIGN.

BIG SCISSORS 5T - FLAT TRACKS

BIG SCISSORS 5T - WHEEL ALIGN.

BIG SCISSORS 5T - TECHNICAL CONTROL

More info Accessories Technical sheet Data sheet

Download

More info

TECHNICAL CHARACTERISTICS

  • Excellent clearance around and under the vehicle.
  • Tracks with hydraulic synchronization without connection shaft for practical access to accessories such as oil collectors and support jacks.
  • « Deadman’s Handle » type of control.
  • Lifting capacity: 4 500 kg
  • Min. height of tracks: 330 mm
  • Tracks width: 700 mm
  • Tracks length: 4 800 mm
  • Max. lifting height: 2 100 mm
  • Loaded lift lifting/lowering time: 30 / 30 secs

Schéma Technique

Side view

4129301D-vues côtés

Top view

Data sheet

Weight700 kg
Power supply230 V 3 ph / 50 Hz / 16.4 A - 400 V 3 ph / 50 Hz / 9.5 A
Power1,8 kW
Vehicle typePassenger Car, Light Duty Vehicle
Hydraulic pressure210 bars
Lifting capacity4500 kg
Lifting/lowering time30 / 30 secs
Auxiliary liftWithout
Aligner front housingWithout
Play detectorsWithout

Download
